Long Range Wireless Safety Sensor for Automatic Gates & Barriers
The Wireless Reflective Photocell Sensor is a reliable safety device designed for automatic gates, garage doors, parking barriers, industrial doors, and access control systems throughout Dubai, Abu Dhabi, Sharjah, and across the UAE. Using advanced optical sensing technology, the sensor detects obstacles and helps prevent accidents by stopping or reversing gate movement when an object, vehicle, or person is detected.
Designed for outdoor installations, this reflective photocell sensor features excellent resistance against strong sunlight, rain, dust, and harsh environmental conditions. Its wireless reflective technology simplifies installation while maintaining reliable and accurate obstacle detection.
With a detection range of up to 15 meters, the sensor provides dependable safety protection for residential, commercial, and industrial automation systems. It is commonly used with sliding gate motors, swing gate motors, garage door openers, boom barriers, rolling shutter motors, and automatic door operators.
The compact wall-mounted design allows easy installation and integration with most automation control boards and access control systems.
Key Features
- Wireless reflective photocell sensor
- 15-meter obstacle detection range
- Suitable for automatic gates and barriers
- Anti-strong sunlight technology
- Rain-resistant outdoor design
- Fast and reliable obstacle detection
- Compact wall-mounted installation
- Low power consumption
- Digital output signal
- Easy installation and setup
Technical Specifications
- Product Name: Wireless Reflective Photocell Sensor
- Sensor Type: Reflective Optical Sensor
- Detection Range: Up to 15 Meters
- Power Supply: DC12-24V / AC9-24V
- Relay Output: 1A Max / 36V
- Output Type: Digital Sensor Output
- Mounting Type: Wall Mount
Electrical Specifications
- Supply Voltage: 12V – 24V
- Working Current: 38mA
- Receiver Current (Rx): 15mA
- Transmitter Current (Tx): 30mA
- Relay Output Capacity: 1A Max 36V
Environmental Specifications
- Operating Temperature: -20°C to +70°C
- Anti-Sunlight Protection
- Rain Resistant Design
- Suitable for Outdoor Installations
- Weather Resistant Construction
Physical Specifications
- Dimensions: 100 × 40 × 35 mm
- Compact Wall Mount Housing
- Industrial Grade Construction
Applications
- Automatic Sliding Gates
- Automatic Swing Gates
- Garage Door Openers
- Parking Gate Barriers
- Industrial Doors
- Rolling Shutter Systems
- Warehouse Entrances
- Access Control Systems
- Commercial Building Entrances
- Security Gate Automation
Benefits
- Improves gate safety
- Detects vehicles and pedestrians
- Prevents gate collisions
- Reliable long-distance sensing
- Works in harsh weather conditions
- Low maintenance operation
- Easy integration with control boards
- Suitable for UAE outdoor installations
Compatible Systems
- Sliding Gate Motors
- Swing Gate Motors
- Garage Door Motors
- Parking Barrier Systems
- Automatic Door Operators
- Rolling Shutter Motors
- Access Control Controllers
- Industrial Automation Systems
Package Includes
- 1 × Wireless Reflective Photocell Sensor
- Mounting Accessories
- Installation Manual
Why Choose This Wireless Reflective Photocell Sensor?
- 15-meter detection range
- Reliable obstacle detection
- Strong sunlight resistance
- Weather-resistant construction
- Compatible with most automation systems
- Low power consumption
- Easy installation
- Professional support available across UAE
Frequently Asked Questions
What is a reflective photocell sensor used for?
A reflective photocell sensor detects obstacles in the path of automatic gates, barriers, and doors to improve safety and prevent collisions.
What is the maximum sensing range?
The sensor can detect objects at distances of up to 15 meters.
Can it be used outdoors?
Yes. The sensor is designed to resist strong sunlight, rain, and outdoor environmental conditions.
What power supply does it require?
The sensor operates on DC12-24V or AC9-24V power supplies.
Which systems is it compatible with?
It is compatible with sliding gates, swing gates, garage doors, parking barriers, rolling shutters, and most automatic access control systems.
