Automatic Swing Door Opener 300 KG UAE

Heavy Duty Automatic Swing Door Operator for Commercial & Industrial Applications

The Automatic Swing Door Opener 300 KG is a heavy-duty automatic door automation system designed for large and heavy swing doors up to 300 kg. Engineered for smooth, reliable, and safe operation, this powerful door operator is ideal for hospitals, commercial buildings, shopping malls, banks, government facilities, industrial entrances, hotels, offices, and public access areas throughout Dubai, Sharjah, Abu Dhabi, and across the UAE.

Featuring an advanced microprocessor controller and a high-performance brushless motor, this automatic swing door operator delivers quiet operation, long service life, and low energy consumption. The system supports both automatic and manual operating modes while offering compatibility with RFID readers, fingerprint access systems, face recognition terminals, PIN code keypads, microwave sensors, push buttons, and fire alarm systems.

The operator provides adjustable opening and closing speeds, hold-open functionality, automatic locking modes, and advanced safety features including obstacle detection and auto-reverse protection. Its robust construction makes it suitable for continuous operation in high-traffic environments and demanding commercial applications.

Main Features

• Suitable for swing doors up to 300 KG
• Automatic and manual operating modes
• Advanced microprocessor control system
• Heavy-duty brushless motor with self-locking technology
• Smooth and low-noise operation
• Adjustable opening and closing speed
• Auto-Reverse safety protection
• Electric lock compatibility
• Fire alarm integration support
• Compatible with multiple access control systems
• Energy-efficient and durable design

Working Modes

• Standalone automatic operation
• Remote control operation
• RFID card access control
• Fingerprint access control
• Face recognition access control
• PIN code access control
• Microwave sensor activation
• Exit button operation

Technical Specifications

• Product Name: Automatic Swing Door Operator
• Maximum Door Weight: 300 KG
• Power Supply: 110V / 220V AC
• Voltage Tolerance: ±10%
• Opening Direction: Pull (Open Inside) / Push (Open Outside)
• Opening Time: 3–7 Seconds / 90°
• Hold Open Time: 1–30 Seconds Adjustable
• Operating Temperature: -20°C to +55°C
• Protection Level: IP12D
• Product Dimensions: 450 × 85 × 100 mm
• Unit Weight: 15 KG

Door Status Functions

• Automatic Mode
• Lock Mode
• One-Way Traffic Mode
• Half Open Mode
• Hold Open Mode

Applications

• Hospitals and Healthcare Facilities
• Commercial Buildings
• Shopping Malls
• Hotels and Resorts
• Government Buildings
• Banks and Financial Institutions
• Office Buildings
• Industrial Facilities
• Educational Institutions
• Public Access Areas

Access Control Compatibility

• RFID Card Readers
• Fingerprint Access Systems
• Face Recognition Systems
• PIN Code Keypads
• Microwave Motion Sensors
• Push Buttons
• Non-Touch Exit Buttons
• Fire Alarm Systems

Package Includes

• 1 × Automatic Swing Door Opener 220V
• 1 × Pull Arm / Push Arm
• 1 × Microwave Sensor
• 2 × Remote Controls
• 1 × English User Manual

Benefits

• Suitable for heavy commercial doors up to 300 KG
• Improves accessibility and convenience
• Reduces physical contact with doors
• Supports modern access control systems
• Quiet and reliable operation
• Heavy-duty brushless motor technology
• Designed for high-traffic environments
• Low maintenance requirements

Why Choose Automatic Swing Door Opener 300 KG UAE?

• Suitable for heavy-duty commercial applications
• Advanced safety and automation features
• Compatible with access control systems
• Reliable performance in UAE conditions
• Easy installation and operation
• Supports hospitals, offices, and industrial facilities
• Smooth and quiet operation
• Professional installation available across UAE

Frequently Asked Questions

What is the maximum door weight supported?

The operator is designed for swing doors weighing up to 300 KG.

Can it work with access control systems?

Yes. It supports RFID, fingerprint, face recognition, keypad access, push buttons, microwave sensors, and fire alarm systems.

Does it include safety protection?

Yes. The system features obstacle detection and auto-reverse safety functionality.

Can it operate during voltage fluctuations?

Yes. The operator supports both 110V and 220V power supplies with ±10% voltage tolerance.

Where can this automatic door opener be installed?

It is suitable for hospitals, commercial buildings, shopping malls, offices, hotels, industrial facilities, and public buildings.
