UHF RFID Long Distance Reader 5M UAE

UHF-105 Long Range RFID Reader for Vehicle Access Control

The UHF-105 UHF RFID Long Distance Reader is a professional vehicle identification and access control solution designed for parking management systems, gated communities, residential compounds, commercial facilities, warehouses, and industrial sites throughout Dubai, Sharjah, Abu Dhabi, and across the UAE.

Using advanced UHF passive RFID technology, the UHF-105 provides reliable tag detection at distances of up to 6 meters. The adjustable reading range allows flexible installation for vehicle access control applications, ensuring fast and accurate identification without requiring drivers to stop or lower windows.

The reader supports multiple communication interfaces including Wiegand 26, Wiegand 34, RS232, and RS485, making it compatible with a wide range of access control systems, parking barriers, gate automation systems, and RFID management platforms. Optional Ethernet, WiFi, and Relay outputs are also available for advanced integration requirements.

Designed for outdoor operation, the UHF-105 features a durable ABS engineering plastic housing and reliable performance under UAE environmental conditions, including heat, dust, and continuous operation.

Key Features

• Long-range RFID reading up to 6 meters
• Adjustable reading distance
• Passive UHF RFID technology
• Fast vehicle identification
• Supports multiple communication protocols
• Compatible with access control systems
• Supports multiple tag detection
• Always Read and Trigger Read modes
• External trigger support
• Durable outdoor-ready construction

Technical Specifications

• Model: UHF-105
• Technology: Passive UHF RFID
• Reading Distance: Up to 6 meters (adjustable)
• Frequency: 920~925MHz
• Dimensions: 227 × 227 × 60 mm
• Working Voltage: 9~12V DC
• Working Current: 150mA
• Operating Temperature: -20°C to +60°C
• Housing Material: ABS Engineering Plastic
• RF Protocol: EPC Global UHF Class 1 Gen 2
• Multiple Tag Identification: <10 Tags

Communication Interfaces

• Wiegand 26
• Wiegand 34
• RS232
• RS485
• Optional RJ45 Ethernet
• Optional WiFi
• Optional Relay Output

Operating Modes

• Always Read Mode
• Trigger Read Mode
• External Trigger Support

Applications

• Vehicle Access Control Systems
• Parking Management Systems
• Residential Compounds
• Gated Communities
• Commercial Buildings
• Industrial Facilities
• Warehouses and Logistics Centers
• Automatic Barrier Systems
• Fleet Management Systems
• RFID Vehicle Tracking

Benefits

• Hands-free vehicle access
• Fast and accurate vehicle identification
• Reduces traffic congestion at entrances
• Easy integration with existing systems
• Reliable long-range performance
• Supports multiple communication protocols
• Low maintenance requirements
• Suitable for UAE weather conditions

Package Includes

• 1 × UHF-105 RFID Long Distance Reader
• Mounting Bracket
• Connection Cable
• User Manual

Why Choose the UHF-105 RFID Reader?

• Long reading distance up to 6 meters
• Reliable passive RFID technology
• Compatible with most access control systems
• Multiple interface options
• Designed for outdoor installations
• Easy integration and setup
• Ideal for vehicle access control
• Professional support available across UAE

Frequently Asked Questions

What is the maximum reading distance?

The UHF-105 can read compatible UHF RFID tags from distances of up to 6 meters depending on installation conditions and tag quality.

Can it work with parking barriers?

Yes. The reader is commonly integrated with parking barriers, automatic gates, and access control systems.

Which communication protocols are supported?

The reader supports Wiegand 26, Wiegand 34, RS232, RS485, and optional Ethernet, WiFi, and Relay outputs.

Can multiple tags be detected?

Yes. The reader supports multiple tag identification for up to 10 tags simultaneously.

Is it suitable for outdoor installations in the UAE?

Yes. The reader is designed to operate in temperatures from -20°C to +60°C and is suitable for UAE outdoor environments.
