Microwave Radar Motion Sensor for Automatic Sliding & Swing Doors
BEA EAGLE 5+ Radar Motion Sensor is a professional automatic door activation sensor designed for sliding automatic doors, swing door automation systems, industrial entrances, and commercial access control applications across UAE.
The BEA EAGLE 5+ uses advanced microwave radar technology combined with intelligent microprocessor control to deliver stable, accurate, and reliable motion detection for automatic door systems.
This automatic door radar sensor supports unidirectional motion detection, ensuring that only approaching movements activate the door, helping reduce unnecessary openings and improve energy efficiency.
The BEA EAGLE 5+ sensor is suitable for automatic sliding glass doors, swing door operators, hospitals, shopping malls, office buildings, hotels, commercial entrances, and industrial automatic door systems.
Designed with BEA planar antenna technology, the EAGLE 5+ provides high detection stability, accurate motion sensing, and reliable daily automation performance.
The adjustable detection field size and shape allow flexible installation and precise sensor configuration according to different entrance requirements and door environments.
The BEA EAGLE 5+ radar sensor supports ceiling and wall mounting configurations with adjustable vertical and lateral tilt angles for professional installation flexibility.
Built with intelligent filtering functionality, the EAGLE 5+ ignores door closing movement when installed on swing door hinge side applications, improving operational efficiency and reducing false activation.
The sensor features compact and durable ABS housing with IP54 protection rating for dependable indoor and outdoor operation in commercial and industrial environments.
Designed for energy-efficient automatic door operation, the BEA EAGLE 5+ helps reduce heat loss and unnecessary door opening cycles in high-traffic facilities.
Suitable for hospitals, retail stores, shopping centers, office buildings, hotels, airports, warehouses, industrial facilities, and automatic entrance systems, the BEA EAGLE 5+ combines advanced microwave detection technology, intelligent automation control, and professional motion sensing performance for installations across Dubai, Sharjah, Abu Dhabi, Ajman, Fujairah, Ras Al Khaimah, Umm Al Quwain, Al Ain, and all UAE.
BEA EAGLE 5+ Features
- Microwave radar motion detection technology
- 24.150 GHz microwave sensor
- Unidirectional motion detection
- Approaching movement activation only
- Adjustable detection field size and shape
- High stability planar antenna technology
- Energy-saving operation
- Suitable for sliding and swing automatic doors
- Flexible mounting installation
- Ignores door closing movement
- Durable ABS housing
- IP54 protection rating
- Professional commercial automation sensor
Applications
- Automatic sliding glass doors
- Swing door automation systems
- Hospitals and healthcare facilities
- Shopping malls and retail stores
- Office buildings and commercial entrances
- Industrial automatic doors
- Hotel entrance systems
- Commercial access control systems
Technical Specifications
- Model: EAGLE 5+
- Brand: BEA
- Technology: Microwave + Microprocessor
- Transmitter Frequency: 24.150 GHz
- Radiated Power: Less than 20 dBm EIRP
- Power Density: Less than 5 mW/cm²
- Detection Mode: Motion
- Minimum Detection Speed: 5 cm/s
- Power Supply: 12–24V AC/DC
- Mains Frequency: 50–60 Hz
- Power Consumption: Less than 2W
- Output Type: Relay Change-over Contact
- Maximum Voltage: 42V AC/DC
- Maximum Current: 1A
- Maximum Power: 30W DC / 42VA AC
- Mounting Height: 1.8m – 5m
- Protection Rating: IP54
- Operating Temperature: -20°C to +55°C
- Dimensions: 120 × 80 × 50 mm
- Vertical Tilt Angle: 0° to 90°
- Lateral Tilt Angle: -30° to +30°
- Housing Material: ABS
- Weight: 215g
Package Includes
- 1 x BEA EAGLE 5+ Radar Motion Sensor
- Mounting Accessories
- User Manual
Why Choose BEA EAGLE 5+ UAE?
- Reliable microwave motion detection
- Energy-efficient automatic door operation
- Reduces unnecessary door openings
- Flexible installation and adjustment
- Suitable for sliding and swing doors
- Durable commercial-grade design
- Professional installation support across UAE
